可选测头

Applicable measuring probes:

轴向测头Axial probes P-A2, P-W2 and P-A4,
切向测头Tangential probes P-T2, P-T4, P-Z2, P-Z4 and P-T4A.

直流测量范围

Measuring range DC:

0-40,000 A/cm

交流测量范围

Measuring range AC:

20-20,000 A/cm

精度

Accuracy:

in the homogeneous field
0-20,000 A/cm ± 2% ± 1 digit,
> 20,000 A/cm ± 3% of the displayed value ± 1 digit

分辨率

Resolution:

0 - 200 A/cm: 0.1 A/cm,
> 200 A/cm: 1 A/cm,
> 10,000 A/cm: 10 A/cm

频率范围

Frequency range AC:

10 Hz – 5 KHz

峰值保持

Peak Hold:

Impulse duration >= 0.1 msec

显示

Display:

graphical PLC operating terminal with menu guidance, display of measured values digital or analog, and trend measurement带菜单引导、数字或模拟测量值显示和趋势测量的图形PLC操作终端

多语言

Multilingual menu navigation:

German / English

数据记录

Data logger:

500次测量

统计Statistics:

计数/大/小/平均/标准偏差

Count / Maximum / Minimum / Average / Standard deviation

连接

Interface:

RS232接口，带USB线与PC机通讯，过程控制用24伏模拟信号接口

RS232 interface with USB cable for communication with PC, 24V analog signal interface for process control

供电Power supply:

230V

尺寸Dimensions:

145 x 145 x 220 mm

重量Weight:

1.8KG
